Copper Cores, XLPE Insulated, PVC Sheathed, Control Cable

Widely Use:

Power transmission and distribution cables: KYJV cables ensure stable power transmission and meet the growing power demand.

Industrial automation cables: KYJV cables can effectively connect automation equipment to improve production efficiency and safety.

Construction engineering cables: On construction sites, KYJV cables are an ideal choice for electrical installations due to their durability and flexibility.

Mining cables: In extreme environments, KYJV cables provide stable power support for mining equipment to ensure safe operations.

Advantage:

Real-time monitoring function

KYJV cable is equipped with online monitoring technology, which can track the operating status and key parameters of the cable in real time. This feature enables users to detect potential problems in time and reduce the risk of failure.

Excellent safety performance

Using high-quality conductors and insulation materials, KYJV cables can still maintain excellent safety in high-voltage environments and provide users with reliable power protection.

High-efficiency transmission

KYJV cable design is optimized, with lower resistance and energy loss, meeting the needs of large-load operation and helping customers reduce operating costs.

Multi-field application

Whether it is high-rise buildings, factory automation systems, or mine power supply, KYJV cables can provide stable and reliable power support.

Technical Data

Cable Model	Structural Features			Conductor nominal cross-sectional area （mm²）
	Shielding Type	Armor Type	Flexible cable	0.5	0.75	1	1.5	2.5	4	6	10
	Shielding Type	Armor Type	Flexible cable	Number of Cores
KVV、KVVP、KYJV、 KYJVP、KYJY、KYJTYP	No or copper wire	None	No	—	2-61				2-19		2-10
KVVP2、KVVP3、KVVP4、 KYJVP2、KYJVP3、KYJVP4、 KYJYP2、KYJYP3、KYJYP4	Metal Strip	Steel belt	No	—	4-61				4-19		4-10
KVV22、KYJV22、KYJY23、 KVVP2-22、KYJVP2-22、 KYJYP2-23	None or copper tape	Steel belt	No	—	7-61		4-61		4-19		4-10
KVV32、KYJV32、KYJY33	None	Steel Wire	No	—	19-61		7-61		4-19		4-10
KVVR	None	None	Yes	2-16					—	—	—
KVVRP	Copper wire	None	Yes	2-61			2-48		—	—	—

Expand all

Only some product parameters are displayed. For more product information, please contact us.

The above parameters are for reference only.

Cable Structure

Control Cable-KYJV

Features

Cross-linked polyethylene maintains the inherent high electrical properties of polyethylene, and has the characteristics of high breakdown strength, high insulation resistance, low dielectric constant, and low dielectric loss.

Cross-linked polyethylene has a low density and the cable has no metal sheath, so the cable is light per unit length and easy to lay.

Cross-linked polyethylene has high heat resistance and anti-aging properties, low dielectric loss, and a long-term allowable operating temperature of 90°C, which greatly improves the transmission capacity.

The use of flame-retardant materials reduces the escape concentration of smoke and harmful combustion gases and improves the safety and reliability of the cable.

Usage Characteristics

Maximum rated operating temperature of conductor: 70°C or 90°C

Maximum short-circuit temperature of conductor: 160°C or 250°C, with a maximum duration of 5 seconds.

Installation and laying temperature: The minimum installation and laying temperature shall not be lower than 0°C.

Laying temperature: The laying temperature in air is 40°C, and the laying temperature in soil is 25°C.

Minimum Bending Radius:

Single-core cable: 20(D+d) ±5%

Multi-core cable: 15(D+d) ±5%
