Control Cable
Control cables encompass a large family of cables for measurement and modulation applications.
Shenxing Cables specializes in manufacturing control cables:KVV, KVVP, KVV22, KYJV, KVVP22, KVVR, KVVRP series copper conductor control cables designed for a wide range of industrial process automation applications, including signal transmission, measurement, control and regulation. These control cables are often referred to by the application, such as machinery supply cable, motor cable and robotics cable. They are also known as multi-core cables, control flex and control flexible cables.
| Cable Model | Structural Features | Conductor nominal cross-sectional area （mm²） | |||||||||
| Shielding Type | Armor Type | Flexible cable | 0.5 | 0.75 | 1 | 1.5 | 2.5 | 4 | 6 | 10 | |
| Number of Cores | |||||||||||
| KVV、KVVP、KYJV、 KYJVP、KYJY、KYJTYP | No or copper wire | None | No | — | 2-61 | 2-19 | 2-10 | ||||
| KVVP2、KVVP3、KVVP4、 KYJVP2、KYJVP3、KYJVP4、 KYJYP2、KYJYP3、KYJYP4 | Metal Strip | Steel belt | No | — | 4-61 | 4-19 | 4-10 | ||||
| KVV22、KYJV22、KYJY23、 KVVP2-22、KYJVP2-22、 KYJYP2-23 | None or copper tape | Steel belt | No | — | 7-61 | 4-61 | 4-19 | 4-10 | |||
| KVV32、KYJV32、KYJY33 | None | Steel Wire | No | — | 19-61 | 7-61 | 4-19 | 4-10 | |||
| KVVR | None | None | Yes | 2-16 | — | — | — | ||||
| KVVRP | Copper wire | None | Yes | 2-61 | 2-48 | — | — | — | |||
1. Strong anti-interference ability: The control cable has good insulation performance and can effectively prevent the influence of external electromagnetic interference on the signal.
2. More cores: Control cables usually have more cores and can be flexibly combined according to different control requirements.
3. Good flexibility: The control cable is very flexible and easy to lay and install.
4. High reliability: The manufacturing process of control cables is strict and the quality is reliable. Its insulation and sheath materials have good wear resistance, corrosion resistance and high temperature resistance, and can work stably for a long time in harsh environments.
1. Industrial and mining enterprises: Various production equipment and control systems in industrial and mining enterprises require the use of control cables to transmit control signals.
2. Energy and transportation sectors: Energy and transportation sectors such as electricity, oil, natural gas, railways, etc. require the use of control cables to achieve control of energy transmission and transportation systems.
3. Construction field: Various automatic control systems in the construction field, such as elevators, fire protection systems, ventilation systems, etc., require the use of control cables to transmit control signals.
4. Other fields: Control cables are also widely used in other fields, such as aerospace, shipbuilding, medical equipment, etc.
Explore our comprehensive range of Control cables. Contact us today for more details or to request a quote.
